4-6 | Thermox Series 2000 WDG-IV / IVC / IVCM
Use the following keys to move directly to a specific location in the ASCII
text table:
Press this Key Move to this Location
1 capital letter A.
3 capital letter Z.
7 small letter a.
9 small letter z.
5 space character.
0 number zero character.
Combustibles and methane scale shown on display
• IfyouselecttodisplayCombustibles, the display will show % com-
bustibles or PPM combustibles, depending on what you selected for
the Combustibles Option from the Setup key.
• IfyouselectMethane, the display will always show % methane.
Option Full Scale Range
% combustibles 0 to 5 %
PPM combustibles 0 - 10,000 PPM
methane 0 to 5 %
An incorrect combustibles reading is always displayed after the initial
installation (the information on the combustibles display line wraps
around to the display line below and over-rides a few characters).
Even though the unit was calibrated at the factory, the analyzer must
be calibrated again after installation. Once the analyzer is calibrated
and the combustibles signal is in the normal range, the display lines
will show the correct reading.
