Controller / User Interface | 4-25
Conguring the relay
1. From the Alarm menu, select Relay Configure.
2. Select De-energize on Alarm or Energize on Alarm.
If you select Energize on Alarm, the following message appears:
Relays are set to
ENERGIZE on Alarm
If you select De-energize on Alarm, the following message appears:
Relays are set to
DE-ENERGIZE on Alarm
Select Function
Select which function Alarm 3 should track.
• % Oxygen
• When the system starts a calibration
• When the system starts a verication
• When the system starts a calibration or a verication (dual function)
When tracking the start of a calibration or verification, the alarm will de-
activate once the calibration or verification has been completed, including
any recovery time you have specified.
Dening the select function
1. From the Alarm menu, select Select Function.
2. Select Alarm3= Oxygen, Alarm3= In Cal., Alarm3= In Verify, or
Alarm3= Cal/Verify, depending on whether Alarm 3 should be associ-
ated with % oxygen levels, or with the start of a calibration or verifi-
cation, or with the start of a calibration or verification, or both (dual
function).
The control unit automatically exits from this menu once you make your
selection.
