5-10 | Thermox Series 2000 WDG-IV / IVC / IVCM
Calibration: Hot Wire Type Combustibles Detector
If you have a Hot Wire-type detector, the zero gas display appears:
O2 xx.x % Set xx.x %
Cmb yyyy Set 0
CH4 zzzz Set 0
Press ENTER to Zero
Display line 2 will only appear if you have the combustibles option;
display line 3 will only appear if you have the combined combustibles
and methane option.
1. Press Enter when the zero gas reading(s) on the left of the display stabi-
lizes. The reading on the far right of the rst display line shows the setpoint
value you entered for the O
2
zero gas using the Cal Gas Values menu
option. This O
2
zero gas setpoint value should match the cal gas cylinder
for the O
2
zero gas.
You are also prompted to apply the combustibles span gas to the calibra-
tion gas inlet port of the sensor (tubing must be free of oil and dirt):
Inject Comb Span Gas
ENTER to Continue
CANCEL to Abort
2. Press Enter when you have applied this calibration gas. You are prompted
to calibrate the combustibles span gas.
If you are calibrating a WDG-IVCM analyzer with a Hot-wire type
catalytic detector, you must have a separate combustibles span and
methane span calibration gas - see the “Mechanical Installation” sec-
tion in Chapter 3 for recommended calibration gases.
O2 xx.x %
Cmb yyyy Set yyyy
CH4 zzzz Set zzzz
Press ENTER to Span Comb
3. Press Enter when the combustibles span gas reading(s) stabilizes on the
far left of the display.
