96 ARX 23-2 T4i, ARX 26-2 T4i
13
12
CAL001
CAL007
B
CAL006
1/4
2/4
1
3/4
9V
15V
13V
B12
11V
SAving
CAL010
1/4
2/4
1
3/4
9V
15V
13V
11V
SAvEd
2.7 Machine operation and use
Select the parameter and press OK to conrm (12).
After all required parameters are set, set the B12 tab and press
the calibration button (B) for 5 seconds.
While the button is held down, the display shows the “Saving”
status.
If the parameters are OK, the data saved and the display shows
the “Saved” status.
If the set parameters are not OK, the display shows the “Err” sta-
tus. The set parameters are not saved and the whole calibration
must be repeated.
To complete the calibration, switch o ignition by turning the
key in the ignition box to the “0” position.
To exit the calibration mode without saving, switch o ignition
or press the calibration button for 5 seconds when the tab is not
set to B12.
