Vibration switch (12)
Press the switch to turn on/o the vibration function.
AMN83
Sprinkling switch (13)
Press the switch to turn on/o the drum sprinkling function.
AMN83
Edge cutter sprinkling switch (14)
Press the switch to turn on/o the edge cutter sprinkling func-
tion.
3355
Edge cutter button – up (15)
Pressing the button sets the edge cutter to the transport posi-
tion.
3355
Edge cutter button – down (16)
Pressing the button sets the edge cutter to the transport posi-
tion.
2246
Warning horn button (15)
595417
Warning lights switch (16)
Ignition box (19)
0 - OFF
I - ON
II - Engine glowing
III - Engine starting
Display (20)
Instrument to display parameters and functions of the engine
and of the machine.
