53ARX 23-2 T4i, ARX 26-2 T4i
OPERATING MANUAL
Hydraulic oil temperature indicator lamp (25)
The hydraulic oil temperature indicator lamp lights up when the
oil temperature exceeds 85°C.
If the oil temperature exceeds 95°C, the error F32 will appear.
Emergency stop indicator lamp (26)
The emergency stop indicator lamp lights if the emergency
brake button (6) is enabled.
If the indicator lamp does not go o when the emergency brake
button is disabled, look for the cause!
The engine can be started only after the defect is repaired!
Fuel indicator lamp (27)
When the fuel indicator lamp lights up, the tank capacity is suf-
cient for half-hour operation of the machine.
Rell the fuel!
Engine glowing indicator lamp (28)
It indicates the engine warming up before the cold start.
Error message indicator lamp (21)
The error message indicator lamp lights up when the control
system detects an error. At the same time, the error code ap-
pears on the display.
• Check the machine according to the table of error message
codes.
If the indicator lamp remains lighting, call the service!
Battery charging indicator lamp (22)
When the battery charging indicator lamp lights up during op-
eration or it does not go o after the engine is started, carry out
the undermentioned steps:
• Stop the engine.
• Check the V-belt of the engine for damage and loosening. If
the indicator lamp is still lit up when the engine is started,
contact the service centre.
Engine lubrication indicator lamp (23)
When the engine lubrication indicator lamp lights up during
operation or does not go o after the engine is started up, you
must stop the machine immediately and turn o the engine!
• Check the engine for oil leaks and for correct oil level.
• If the oil level in the engine is correct, call the service!
Engine overheating indicator lamp (24)
When the engine overheating indicator lamp lights up during
operation, turn o the engine and rell the coolant! Check the
cooling circuit for leaks! Check the hoses for damage and miss-
ing hose clips.
