EWCIE Technical Manual
3 Specifications
25Watt**
50Watt**
120Watt 250W 500Watt
Supply
Voltage
27VDC (nominal) 240Vac / 27Vdc
Max Audio
Load
25W
50W
120W
250W
500W
* Requires ASL
Quiescent
Current (no
audio or
strobe load)
20mA 20mA 240mA 380mA 500mA
Max.
Current (full
audio load,
no strobe
load)
1.19A 2.39A 8A 17A 35A
THD 0.12% 0.89% <0.6% <0.6% <0.5%
Signal to
Noise Ratio
80.5dB 82.1 dB 91dB 91dB >90dB
Dimensions
(mm)
100(L)x77(W)x35(H) 170(L)x210(W)x85(H)
300(L)x240(W)x95(H)
483(W)x380(D)x88(H)
Strobe
Output
Monitored 1A max, EOL 10kΩ 5% 1/3 Watt
8 Xenon sets (208-0011) or 40 LED sets (4107-10005)
Cable Recommendation: Ampac TPS FLAT 2C 1.5MM‚ WH STRIPE or similar
100V Audio
Output
100VAC, Monitored EOL Nominal 47kΩ 5% 1/3 Watt (2 branches use 100kΩ 5% ¼ Watt)
Cable Recommendation: Ampac TPS FLAT 2C 1.5MM‚ WH STRIPE or similar
Alert / Evac
Changeover
time (secs)
Alert only, Evacuate only, 60, 90, 120, 180, 300 or under manual control via inputs (see section
5.2)
Alert Signal To AS1670.1 and NZS4512 including voice message
Evac Signal To AS1670.1 and NZS4512 including voice message
Front Controls** Zone Indicator** Audio Line Splitter**
RPC**
Quiescent
Current
10.5mA 10.5mA 10.5mA 5.5mA
Max Per
System
1 1 4 (2 max per amp) 1
Emergency
Zones
Up to 8 Emergency Zones can be configured and programmed
Paging
Zones
Up to 8 Paging Zones can be configured and programmed.
Standalone
Cabinet
PSU Options: 3A, 5A and 10A
Colour: Surfmist
Dimension: 500mm (H) x 405mm (W) x 150mm (D)
Temp -20°C to 70°C
Humidity 0-95% non-condensing
Note ** Denotes third party compliance to AS4428.16:2015
