Ampac LoopSense User Manual

Page 22
LOOPSENSE EN54 USER MANUAL
ACTION:<action type> <dev type>
AVALUE:XXX I:000 O:000 DRIFT:YYY%MODE:X
◄BACK:DISABLE 2:SUB ADDR 3:PRINT
4:ALARM LED ON
Note: Option 2 shall be SUB ADDR (Sub-Address) or REM O/P (Remote Output) depending on
the type of device being displayed.
Input Screens:
Pressing DEVICE ► will also reveal the panel Input Control.
Use the ▼▲ arrows to display the available panel inputs
<point location> <status>
<point descriptor>
ACTION:<action type>
◄BACK 1:DISABLE 2:ON 3:PRINT
7.2.2 Menu > Control > Device
DEVICE
2
L1 L2
1 2
ALARM LED ON
DISABLE
1 2 3 4
SUB ADDR / REM I/O PRINT
NOTE: SUB ADDR AND REM O/P DEPEND
ON THE SELECTED DEVICE
NON
SOUNDER
SOUNDER
1
DISABLE
DISABLE
1
2
ON
2
ALERT
3
PRINT
3
EVAC PRINT
4
ZONE
1
CONTROL
2
ABC
2
ABC
Selecting DEVICE from the control menu; the user shall be prompted to select loop and device
address via generic point selection screens. The following device control menu shall be presented
next:
Zzzz Ppp Lll Dddd.s <status>
<device descriptor>
◄BACK 1:DISABLE 2:SUB ADDR 3:PRINT
4:ALARM LED ON MORE ►
On the 4x40 LCD the Device control menu is split into two screens and the user can navigate
between these screens by selecting MORE► and ◄BACK.
ACTION:<action type> <dev type>
AVALUE:XXX I:000 O:000 DRIFT:YYY MODE:X
◄BACK 1:DISABLE 2:SUB ADDR 3:PRINT
4:ALARM LED ON
Selecting “2: SUB ADDR” will display the generic sub address selection screen if configured. Also
“2: SUB ADDR” will be replaced with “2: REM O/P” if the context displayed is a detector.
Input Screens:
<input location> <status>
<input descriptor>
ACTION:<action type> <dev type>
◄BACK 1:DISABLE 2:ON 3:PRINT
