LOOPSENSE EN54 USER MANUAL
7.2.3.2 Menu->Control->Panel->Output
CONTROL PANEL OUTPUT MENU
1►SUPERVISED O/P 3|OPEN COLLECTOR O/P
2|RELAY O/P 4|AUXILIARY O/P
7.2.3.2.1 Menu->Control->Panel->Output->Supervised O/P
Use the ▼▲ arrows to display the 4 available panel supervised outputs
Non-Sounder Outputs:
Zzzz Ppp SUP:Oo <status>
<output descriptor> <type>
<assigned output type>
◄BACK 1:DISABLE 2:ON 3:PRINT
Sounder Outputs:
Zzzz Ppp SUP:Oo <status>
<output descriptor> <type>
<assigned output type>
◄BACK 1:DISABLE 2:ALERT 3:EVAC 3:PRINT
7.2.3.2.2 Menu->Control->Panel->Output->Relay O/P
Use the ▼▲ arrows to display the 3 available panel relay outputs
Zzzz Ppp RLY:Oo <status>
<output descriptor> <type>
<assigned output type>
◄BACK 1:DISABLE 2:ON 3:PRINT
7.2.3.2.3 Menu->Control->Panel->Output->Open Collector O/P
Use the ▼▲ arrows to display the 2 available panel open collector outputs
Zzzz Ppp OC:Oo <status>
<output descriptor> <type>
<assigned output type>
◄BACK 1:DISABLE 2:ON 3:PRINT
7.2.3.2.4 Menu->Control->Panel->Output->Auxiliary O/P
Use the ▼▲ arrows to display the 2 available panel open collector outputs
Zzzz Ppp AUX:Ooo <status>
<output descriptor> <type>
<assigned output type>
◄BACK 1:DISABLE 2:ON 3:PRINT
7.2.3.3 Menu->Control->Panel->Add-On
SELECT ADD-ON TYPE: 8-WAY RELAY
CHANGE▼
◄BACK NEXT►
After the type of Add-On is selected the generic Add-On point selection screen is presented allowing
the Add-On address to be selected. The Add-On control menu is then presented:
