LOOPSENSE EN54 USER MANUAL
Use the alpha-numeric keys to key in descriptor characters. Pressing next (or
enter) will update the programming.
DAY MODE
ZONE CONFIGURATION: INVESTIGATION
CHANGE▼
◄BACK NEXT►
For day and night mode, choices are:
 NORMAL (No Timeout)
 INVESTIGATE (Timeout 1 / 2, MCP Override, Inhibit Sounders, Inhibit Fire Outputs
 DEPENDANCY A (Timeout 1)
 DEPENDANCY B (Timeout 1)
 DEPENDANCY C (Inhibit Sounders, Inhibit Fire Outputs)
Pressing next (or enter) will update the programming and prompt for respective timeout 1 setting.
DAY MODE <zone configuration>
EDIT ZONE TIMEOUT 1: 60 (1-180 SECS)
#CLEAR
◄BACK NEXT►
Pressing next (or enter) will update the programming and prompt for respective timeout 2 setting.
DAY MODE <zone configuration>
EDIT ZONE TIMEOUT 2: 300 (1-420 SECS)
#CLEAR
◄BACK NEXT►
Pressing next (or enter) will update the programming and prompt for MCP override setting.
DAY MODE <zone configuration>
MCP OVERRIDE: ENABLED
CHANGE▼
◄BACK NEXT►
Pressing next (or enter) will update the programming and prompt for Inhibit sounders setting.
DAY MODE <zone configuration>
INHIBIT SOUNDERS: ENABLED
CHANGE▼
◄BACK NEXT►
Pressing next (or enter) will update the programming and prompt for Inhibit fire outputs setting.
DAY MODE <zone configuration>
INHIBIT FIRE OUTPUTS: ENABLED
CHANGE▼
◄BACK NEXT►
The screens are then repeated for night mode. Then the user will be prompted to save changes if
required.
7.6.2 Menu->Programming->Device
DEVICE MENU
1►ADD
2|DELETE
3|EDIT
The user may choose to Add, Edit or Delete devices. Once selected, the user will be prompted to
select the loop and device to which to perform the selected action using the generic point selection
screens.
