1 About This Manual
1.1 Introduction
This manual contains all the information required to operate the LoopSense Fire Alarm Control
Panel (FACP). The first step in becoming a proficient operator is to be familiar with and understand
the “Menu Structure” and the keys used to navigate through it. Once this concept along with the
screen prompts that are displayed during the navigation process are understood the user will find the
operation of the LoopSense Fire Alarm Control Panel (FACP) a simple task.
2 Introduction
2.1 System Overview
The purpose of the LoopSense Fire Alarm Control Panel (FACP) is to monitor changes in inputs,
report those changes and update selected outputs as programmed.
The FACP processes changes in inputs such as fire, fault, pre-alarm, emergency, security, user,
transparent and system and has a built-in menu structure to view its status, perform operational
tests, and modify the panel’s configuration and programming.
The LoopSense FACP is compliant with EN54-2 and EN54-4.
In addition to the mandatory requirements of EN54-2 the LoopSense meets the following optional
features with requirements:
7.8 Output to fire alarm devices
7.9 Control of fire alarm routing equipment
7.9.1 Output to fire alarm routing equipment
7.9.2 Alarm Confirmation input from fire alarm routing equipment
7.11 Delays to outputs
7.12 Dependencies on more than one alarm signal Type A, B and C
8.3 Fault signals from points
8.9 Output to fault warning routing equipment
9.5 Disablement of each addressable points
10 Test condition
