LOOPSENSE EN54 USER MANUAL
TYPE: <device type>
1 DEVICE
2►SUB ADDRESS
NEXT►
If the device type has sub-address inputs or outputs this screen is displayed next:
SELECT SUB ADDRESS: 1
<selected sub address descriptor>
1►I/P1 2:I/P2 3:I/P3 4:O/P1 5:O/P2
6:O/P3
Select 2 SUB ADDRESS and pressing NEXT► displays the generic sub-address selection screen:
EDIT DESCRIPTOR
LOOP 1 DEVICE 1 INPUT 1_
#CLEAR DEL▲
◄BACK NEXT►
Select one of the sub inputs and press enter to edit the input configuration.
ENTER ZONE NUMBER: 1_
◄BACK NEXT►
Press NEXT► to go to the next field.
EDIT ACTION TYPE: FIRE
CHANGE▼
◄BACK NEXT►
Press NEXT► to go to the next field.
INPUT TYPE: NON-LATCHING
CHANGE▼
◄BACK NEXT►
Press NEXT► to go to the next field.
EDIT CONTACT STATE: NORMALLY OPEN
CHANGE▼
◄BACK NEXT►
Press NEXT► to go to the next field.
SUPERVISED: ENABLED
CHANGE▼
◄BACK NEXT►
Press NEXT► to go to the next field.
EDIT PRE-DELAY: 0 (0-90 seconds)
#CLEAR DEL ▲
◄BACK NEXT►
Press NEXT► to go to the next field.
The user is then prompted to save any changes that may have been made.
7.6.2.5 Menu->Programming->Device->Edit – Sub Output
