AmScope T720 Series User Manual

T720 Series Microscope
AmScope Proprietary Page 26 of 46
3. General Specifications
3.1 Features
FEATURE SPECIFICATION
Optical System Infinity corrected
Nosepiece Reversed, ball bearing quintuple
Head Gemel type trinocular head, 30-degree inclined
Infinity Plan Objectives 4X, 10X, 20X, 40X (spring), 100X (spring, oil)
Focusing Low position coaxial focus system
Interpupillary Adjustment Range 2-3/16" - 3" (55-75mm)
Mechanical Tube Length 6-5/16" (160mm)
Mechanical Stage 8.5" x 5.9" (216mm x 150mm)
Stage Traveling Range 2.9" x 2" (75x50mm)
Focusing Range 0.95" (24mm)
Division of Fine Focusing 0.00003935" (0.001mm)
Illumination Built-in Kohler LED Illumination System
Condenser N.A. 1.25/0.22 Swing Achromatic Condenser
Power Supply 90V-240 Wide Voltage, CE Certified
3.2 Eyepiece Comparison
EYEPIECES T720 T720QC T720-TP T720-HD18 T720QC-TP T720QC-HD18
PL10X22mm ● ● ● ● ● ●
WF25x30mm ● ● ●
3.3 Eyepiece Parameters
Eyepieces
Magnification
5X 10X 15X 16X 20X 25X
Field of View
Φ18 Φ18 Φ13 Φ15 Φ11 Φ9
