Appendix B - Commands / Messages
65
Tango Series Audio Controllers
Controller Status Messages (Cont.)
MGSTr,v,bb,t,s,
r,z,l,p
(Cont.)
•‘p’ denotes the privacy status, valid values are:
0: Off
1: On
MRGSz,s,b8,b7,b6,
b5,b4,b3,b2,b1
Room Grouping Status, where:
•‘z’ is the group ID, valid values are:
0: no group ID – all rooms in selection are not in a grouping
1-32: group ID
•‘s’ is the source the rooms are currently associated with
•‘b8’…’b1’ is a binary room selection bitmap where all rooms to be grouped have a
binary 1 in the room position. The most significant bit in ‘b8’ is for room 64 and the
least significant bit in ‘b1’ is for room 1.
Note: If none of the bits are set in the room selection bitmap, then the room grouping
has been removed.
MGRSs,b8,b7,b6,
b5,b4,b3,b2,b1
Source Grouping Status, where:
•‘s’ is the source who the rooms are listening to
•‘b8’…’b1’ is a binary room selection bitmap where all rooms listening to ‘s’ have a
binary 1 in the room position. The most significant bit in ‘b8’ is for room 64 and the
least significant bit in ‘b1’ is for room 1
MFAVr,s,f Favorite Status, where:
•‘r’ is the room, (1-64)
•‘s’ is the source, valid values are 1-8
•‘f’ is the direct tuning string; it can be from 0 to 7 characters long and is translated as
specified in the ‘Send Source Direct Data’ command: Zero length data is returned if
the favorite is not set
MLOTb8,b7,b6,
b5,b4,b3,b2,b1
Lock Out Status, where:
‘b8’…’b1’ is a binary room selection bitmap where all rooms blocked out have a
binary 1 in the room position. The most significant bit in ‘b8’ is for room 64 and the
least significant bit in ‘b1’ is for room 1
MPRSs,n,p Preset Status, where:
•‘s’ is the source, valid values are 1-8
•‘n’ is the preset, valid values are 1-10
•‘p’ is the direct tuning string; it can be from 0 to 7 characters long and is translated
as specified in the ‘Send Source Direct Data’ command: Zero length data is
returned if no preset is set
MSTPs,t Source Type Status, where:
•‘s’ is the source, valid values are 1-8
•‘t’ is the source type, valid values are:
0: undefined
1: AM/FM Tuner
2: CD Changer
3: DVD Player
4: Satellite Receiver
5: Audio Server
6: Other 1
20: Internal AM/FM Tuner
