Instruction Manual - Solecis Digital Switchers
SDX-410-DX Specifications (Cont.)
Optional Accessories: • AVB-VSTYLE-SURFACE-MNT, V Style Module Surface Mount (FG1010-722)
• NMX-VRK V Style Rack Shelf (FG3201-60)
• AVB-VSTYLE-POLE-MNT, V Style Module Pole Mount (FG1010-723)
• MET-6N, Metreau 6-Button Keypads with Navigation (FG5794-01-WH/BL)
• MET-7, Metreau 7-Button Keypads (FG5794-03-WH/BL)
• SP-08-AX-US, 8-Button KeyPads (US) with AxLinx (FG1311-08-SW/SB/SA)
• SP-08-AX-UK, 8-Button KeyPads (UK) with AxLinx (FG1311-08-KW/KB/KA)
• SP-08-AX-EU, 8-Button KeyPads (EU) with AxLinx (FG1311-08-EW/EB)
• HydraPort with HPX-U400-MET-6N, Metreau 6-Button Keypad Kit with Carrier
(FG554-11-BL-K)
• HydraPort with HPX-U400-MET-7 Metreau 7-Button Keypad Kit with Carrier
(FG554-13-BL-K)
• HydraPort with HPX-U400-R-MET-6N Metreau 6-Button Keypad Ramp Mount Kit
(FG564-11-BL)
• HydraPort with HPX-U400-R-MET-7 Metreau 7-Button Keypad Ramp Mount Kit
(FG564-13-BL)
• CBL-HDMI-FL, HDMI High Speed Flat Cable with RedMere Technology (FG10-2180-16)
• CBL-DP-FL, DisplayPort High Speed Flat Cable with RedMere Technology (FG10-2181-16)
• CBL-ETH-FL, Ethernet Flat Cable (FG10-2182-16)
• CBL-RGB+A-FL, RGB with Audio Flat Cable (FG10-2183-16)
• CC-USB, USB Programming Cable (FG10-5965)
Signal Transport - DXLink:
Connector: (1) RJ-45
Supported Signal
Styles:
Digital video, audio, Ethernet, bi-directional control
Transport Layer
Throughput (Max):
10.2 Gbps
Twisted Pair Cable
Type:
Shielded Cat6, Cat6A and Cat7
DXLink twisted pair cable runs for DXLink equipment shall only be run within a common
building where a common building is defined as: the walls of the structure(s) are
physically connected and the structure(s) share a single ground reference.
For more details and helpful cabling information, reference the white paper titled Cabling for
Success with DXLink, or contact your AMX representative.
Twisted Pair Cable
Length:
Up to 328 ft. (100 m)
HDCP Support: Yes
Active Power Requirements:
Voltage, DC (Typical): 12 VDC
Power Consumption
(Max):
18 W
Power Connector: 2-pin 3.5mm Screw Retention Connector
External, Required Optimal performance requires use of one of the following AMX power supplies (not included):
• PSR4.4, 13.5 VDC, 4.4 A Power Supply with 3.5mm Phoenix Connector with Retention
Screws (FG423-46)
• PSN6.5, 13.5 VDC, 6.5 A Power Supply with (3) 3.5mm Phoenix Connectors (FG423-41)
Environmental:
Temperature
(Operating):
32° F to 104° F (0° C to 40° C)
Temperature (Storage): -22° F to 158° F (-30° C to 70°C)
Humidity (Operating): 5% to 85% non-condensing
Humidity (Storage): 0% to 90% non-condensing
