Overview
6
Instruction Manual - Solecis Digital Switchers
SDX-510M-DX Specifications (Cont.)
Active Power Requirements:
Voltage, AC (Typical): 110-240VAC, 47-63 Hz
Power Consumption
(Max):
48 W
Power Connector: IEC Power Cord Connector 100-240 VAC 47-63 Hz
DXLink Power: Supplies power to a DXLink Twisted Pair RX, when used in point-to-point applications
Power Supply:
Internal, Included Yes
Environmental:
Temperature
(Operating):
32° F to 104° F (0° C to 40° C)
Temperature (Storage): -22° F to 158° F (-30° C to 70°C)
Humidity (Operating): 5% to 85% non-condensing
Humidity (Storage): 0% to 90% non-condensing
USB (HID) Keyboard and Mouse:
USB (HID) (1) USB Type Connector ("TO HOST"); connect a Solecis Digital Switcher with DXLink to a PC
and emulate keyboard and mouse commands from a DXLink Receiver
Front Connectors:
ID Pushbutton: (1) ID Pushbutton, can be used to assign the unit’s Device ID, switch between Static and
Dynamic IP addressing modes, and reset the unit to factory defaults.
AxLink Keypad Control: (1) 4-pin, 3.5mm Screw Terminal Connector
Ethernet LAN OUT: (3) RJ-45 Connectors
HDMI Output: (1) HDMI Type A Female Connector
DXLink Output: (1) RJ-45 Connector
USB Host Port: (1) USB Type B Connector "TO HOST"
USB Device Port: (1) USB Type A Connector, reserved for future use
Back Connectors:
Advanced
Configuration Interface:
(1) USB Mini-B Connector
HDMI Inputs: (3) HDMI Type A Female Connectors
VGA Inputs: (2) HD-15 Connectors
Single External Button/
LED Control Connector:
(1) 3-pin, 3.5mm Screw Terminal Connector
Dual External Button/
LED Control Connector:
(2) 5-pin, 3.5mm Screw Terminal Connectors
Analog Stereo Inputs: (2) 1/8" mini-Stereo Jack
AC Power Connection: IEC Power Cord Connector
Ethernet:
Ethernet Connections: (3) RJ-45, 10/100 Port provides TCP/IP communication. This is an Auto MDI/MDI-X enabled
port, which allows you to use either straight-through or crossover Ethernet cables. The
Ethernet Port LEDs show communication activity, connection status, speeds, and mode
information.
Ethernet Link/Act
Indicator:
(1) Link/Activity LED (green) blinks when receiving Ethernet data packets, one on Ethernet
RJ-45 connector and one on the front panel.
Ethernet Speed
Indicator:
(1) Speed LED (yellow) lights On when the connection speed is 100 Mbps Ethernet connection
and turns OFF when the speed is 10 Mbps
