Overview
7
Instruction Manual - Solecis Digital Switchers
SDX-510M-DX Specifications (Cont.)
Controls & Indicators:
AxLink Keypad Port: (1), 4-pin 3.5 mm captive-wire connector, provides data and power to up to 2 external AxLink
Keypads
AxLink Indicator: (1) AxLink Keypad LED (green) indicates the state of the AxLink Keypad port
LINK/ACT Indicator: (1) LED (green), lights when the Ethernet cable is connected and an active link is established.
This LED also blinks when receiving Ethernet data packets
Status Indicator: (1) LED (green), indicates boot and connection status
Power Indicator: (1) Power LED (green) indicates the unit is powered on
ID Pushbutton: (1) ID Pushbutton, can be used to assign the unit’s Device ID, switch between Static and
Dynamic IP addressing modes, and reset the unit to factory defaults.
Integrated Switcher:
Video Switching: 5x1 (dual) audio/video switching, any of 5 inputs can be routed to the HDMI and DXLink output
simultaneously
Video Inputs: • (2) HD15; supports RGB
• (3) HDMI; supports HDMI/HDCP
Video Outputs: • (1) HDMI; supports HDMI/HDCP
• (1) DXLink; supports digital video, audio, Ethernet, and bi-directional control
HDCP Support: Yes
HDMI:
Compatible Formats: HDMI, HDCP, DVI
Input Signal Type
Support:
HDMI
DVI-D (Single Link with Cable Adapter)
Display Port ++ (Input Only, with HDMI Cable Adapter)
Input Connectors: (3) HDMI Type A Female
Output Signal Type
Support:
HDMI, HDCP, DVI
Input Re-clocking
(CDR):
Yes
Deep Color Support: Yes
Color Space Support: RGB 4:4:4
YCbCr 4:4:4 and 4:2:2
(Input signal support for YCbCr 4:4:4 and 4:2:2, output color-space is converted to RGB 4:4:4)
3D Format Support: Yes (HDMI Primary Formats)
Frame Packing 1080p up to 24Hz
Frame Packing 720p up to 50/60Hz
Frame Packing 1080i up to 50/60Hz
Top-Bottom 1080p up to 24Hz
Top-Bottom 720p up to 50/60Hz
Side-by-Side Half 1080p up to 50/60Hz
3D supported when the HDMI DXLink
RX Scaler is in Bypass mode and format is 1080p60 or less
Audio Format Support: Dolby TrueHD, Dolby Digital, DTS-HD Master Audio, DTS, 2 CH through 8 CHL-PCM Dolby
Digital and DTS support up to 48kHz, 5.1 channels
Audio Resolution: 16 bit to 24 bit
Audio Sample Rate: 32 kHz, 44.1 kHz, 48 kHz, 96 kHz, 192 kHz
