Overview
11
Instruction Manual - Solecis Digital Switchers
SDX-810-DX Specifications (Cont.)
Integrated Switcher:
Video Switching: 8x1 (dual) audio/video switching, any of 8 inputs can be routed to the HDMI and DXLink output
simultaneously
Video Inputs: (8) HDMI; supports HDMI/HDCP
Video Outputs: • (1) HDMI; supports HDMI/HDCP
• (1) DXLink; supports digital video, audio, Ethernet, and bi-directional control
HDCP Support: Yes
Select Pushbutton: Press to manually switch the input routed to the output. Each press switches to the next input in
order, or if the last input is currently selected, switches to the first input.
HDMI:
Compatible Formats: HDMI, HDCP, DVI
Input Signal Type
Support:
HDMI
DVI-D (Single Link with Cable Adapter)
Display Port ++ (Input Only, with HDMI Cable Adapter)
Input Connectors: (8) HDMI Type A Female
Output Signal Type
Support:
HDMI, HDCP, DVI
Input Re-clocking
(CDR):
Yes
Deep Color Support: Yes
Color Space Support: RGB 4:4:4
YCbCr 4:4:4 and 4:2:2
(Input signal support for YCbCr 4:4:4 and 4:2:2, output color-space is converted to RGB 4:4:4)
3D Format Support: Yes (HDMI Primary Formats)
Frame Packing 1080p up to 24Hz
Frame Packing 720p up to 50/60Hz
Frame Packing 1080i up to 50/60Hz
Top-Bottom 1080p up to 24Hz
Top-Bottom 720p up to 50/60Hz
Side-by-Side Half 1080p up to 50/60Hz
3D supported when the HDMI DXLink
RX Scaler is in Bypass mode and format is 1080p60 or less
Audio Format Support: Dolby TrueHD, Dolby Digital, DTS-HD Master Audio, DTS, 2 CH through 8 CHL-PCM Dolby
Digital and DTS support up to 48kHz, 5.1 channels
Audio Resolution: 16 bit to 24 bit
Audio Sample Rate: 32 kHz, 44.1 kHz, 48 kHz, 96 kHz, 192 kHz
HDCP Support: Yes
Supports AMX HDCP InstaGate Pro Technology
When used with an AMX Digital Media Switcher the key support is up to 16 sinks per output,
independent of source device.
When used as a single point-to-point solution the key support is defined by the source device.
