SECTION 6 PERFORMANCE TESTS
6-12
• MS2667C
Signal Center Span
Band
Frequency readout
generator frequency frequency Minimum value Maker value Maximam value
10 kHz 499.999 5 MHz 500.000 5 MHz
500 MHz 500 MHz 200 kHz 0 (1) 499.99 MHz 500.01 MHz
100 MHz 495 MHz 505 MHz
10 kHz 4.999 999 4 GHz 5.000 000 6 GHz
5 GHz 5 GHz 200 kHz 1– (1) 4.999 99 GHz 5.000 01 GHz
100 MHz 4.995 GHz 5.05 GHz
10 kHz 7.499 999 3 GHz 7.500 000 7 GHz
7.5 GHz 7.5 GHz 200 kHz 1+ (1) 7.499 99 GHz 7.500 01 GHz
100 MHz 7.495 GHz 7.505 GHz
10 kHz 11.999 998 8 GHz 12.000 001 2 GHz
12 GHz 12 GHz
200 kHz
2+ (2)
11.999 99 GHz 12.000 01 GHz
100 MHz 11.995 GHz 12.005 GHz
1 GHz 11.95 GHz 12.05 GHz
10 kHz 19.999 998 1 GHz 20.000 001 9 GHz
20 GHz 20 GHz
200 kHz
3+ (3)
19.999 99 GHz 20.000 01 GHz
100 MHz 19.995 GHz 20.005 GHz
1 GHz 19.95 GHz 20.05 GHz
10 kHz 28.999 998 9 GHz 29.000 001 1 GHz
29 GHz 29 GHz
200 kHz
4+ (4)
28.999 99 GHz 29.000 01 GHz
100 MHz 28.995 GHz 29.005 GHz
1 GHz 28.95 GHz 29.05 GHz
