SECTION 4 SOFT-KEY MENU
4-3
SECTION 4
SOFT-KEY MENU
In this section, soft-key menu functions and its hierarchical system are described using a tree.
Matters to be noted about the tree are shown below.
(1) Panel Key indicates a hard key on the front panel.
(2) Top menus are the menus at the top level which are displayed on the screen when the panel key is pressed.
Lower menus indicates other menus below the top menus.
(3) When a soft key with an appended asterisk (*) is pressed in these menus, the menu moves to the lower
menu indicated by the arrow symbol (->). However, if any not-supported-function soft key in an Option is
pressed, an error message is displayed.
(4) When the Return key is pressed at a lower menu, the next-higher menu is returned.
(5) Menus with more than six items are split into several pages.
(6) The menu page construction and currently-displayed page are indicated in the lower part of the menu. To
move to the next page, press the [More] key.
(7) Panel keys and soft keys prefixed by a sharp symbol (#) at the left of the menu frame, give an outline
explanation of the function.
