SECTION 1 GENERAL
1-3
SECTION 1
GENERAL
Product Outline
The MS2665C/67C/68C spectrum analyzer (henceforth called "this unit") is a portable type color LCD spectrum
analyzer suited for signal analyses of radio equipment where the efficiency of frequency usage is increased and
equipment are increasingly speeded and digitized.
Excellent in basic performance such as C/N, distortion, frequency/level accuracy, and easily operable following
the display of the soft-key menu screen.
Excellent cost performance with rich options to cope with various applications.
Equipped with high-accuracy calibration signals and an attenuator, it can accurately calibrate switching errors
of LOG/LIN scales, resolution bandwidth, reference level, etc. Since frequency response is corrected by built-
in calibration data, it allows high-accuracy level measurement for a wide range.
As the switching of waveforms between frequency domain and time domain can be done by a touch and two
waveforms are simultaneously displayed, signal analyses of both domains can be done efficiently. Moreover,
our original zone marker function and multi-marker function (up to 10 markers) are also special mention.
This unit provides the MEASURE function that can perform measurement of various applications without
requiring the intervention of external controllers. Therefore, the performance evaluation of radio equipment
can be easily done in terms of frequency, noise, occupied frequency bandwidth, leak power from neighboring
channels, etc.
In addition, as the template measurement of burst mean power and burst waveform are also available, it is
suited for evaluating the performance of digital radio equipment.
■ Application
This unit is useful for the production, building and maintenance of electronic equipment and devices in the
following fields.
• AM/FM radio equipment
• Digital cellular telephone/cordless telephone
• Satellite broadcasting, CATV and TV equipment
• Microwave equipment
