SECTION 3 PANEL DESCRIPTION
3-3
SECTION 3
PANEL DESCRIPTION
In this section, the front and rear panels (Figs. 3-1 and 3-2) are described about the case in which all the options
are attached to.
Table of Front and Rear Panel Features
No. Panel Marking Explanation of Function
1 (LCD) This is a 5.5 ” color TFT liquid crystal display (LCD). It displays the
trace waveforms, theparameter settings, the values of marker, and the
soft menu keys, etc.
2 Menu On/Off This toggles the soft-key menu display On/Off.
3 F 1-F 6 These are the soft keys for selecting the soft-key menus linked to the
panel key operation.
4 More This displays the next page of soft-key menus.
5 Freq/Ampl This is the frequency and level parameter data input section.
[Frequency] Sets frequency.
[Span] Sets frequency span.
[Amplitude] Sets reference level.
[– > CF] Sets peak level signal frequency on screen to center
frequency.
[– > RLV] Sets peak level on screen to reference level.
6 Marker This section is related to operation of marker functions.
[Marker] Sets marker.
[Multi Mkr] Sets multimarkers.
Press this key after pressing the [Shift] key.
[Peak Search] Moves marker to currently-displayed peak level.
[Marker – >] Sets parameter according to marker value.
Press this key after pressing the [Shift] key.
7 User This is a user-dedicated key which users can specify.
