SECTION 1 GENERAL
1-6
Options
The table below shows the options for the MS2665C/2667C which are sold separately.
† Please specify the model/order number, name, and quantity when ordering.
Model-†Order No.† Name Remarks
MS2665C-01 Reference crystal oscillator stability ≤2 ×10
–8
/day
MS2665C/2667C/
Narrow resoluion bandwidth 30 Hz/100 Hz, 300 Hz
MS2668C-02
MS2667C/2668C-03 Narrow resoluion bandwidth 10 Hz, 30 Hz, 100 Hz, 300 Hz
MS2665C/2667C/ High-speed time domain
1.25 µs/div
2668C-04 sweep
MS2665C/2667C/
Trigger/Gate circuit Pre-trigger and post trigger avilable
2668C-06
MS2665C/2667C/ AM/FM demodulator Output to loudspeaker or earphone
2668C-07 (Sound monitor) connector
MS2665C/2667C/
Centronics interface Not possible when GPIB installed
2668C-10
MS2665C-14 PTA Parallel I/O
Controlling external equipment from PTA.
Not possible when Option 10 installed
MS2665C/2667C/
Sweep signal output X, Z
2668C-15
