Anritsu MS2665C - Page 147

SECTION 6 PERFORMANCE TESTS
6-16
Frequency-Span Readout-Accuracy Test
• MS2665C
MS2665C Signal generator Results
20 kHz 0.999 99 2 GHz 1.000 008 GHz 19.5 kHz 20.5 kHz
200 kHz 0.999 92 GHz 1.000 08 GHz 195 kHz 205 kHz
1 GHz 2 MHz 0.999 2 GHz 1.000 8 GHz 1.95 MHz 2.05 MHz
10 MHz 0.996 GHz 1.004 GHz 9.75 MHz 10.25 MHz
100 MHz 0.96 GHz 1.04 GHz 97.5 MHz 102.5 MHz
2 GHz 0.2 GHz 1.8 GHz 1.95 GHz 2.05 GHz
100 kHz 4.21 GHz 4.29 GHz 97.5 MHz 102.5 MHz
4.25 GHz 1 MHz 3.85 GHz 4.65 GHz 0.975 GHz 1.025 GHz
8.5 MHz 0.85 GHz 7.65 GHz 8.2875 GHz 8.7125 GHz
100 MHz 10.56 GHz 10.64 GHz 97.5 MHz 102.5 MHz
10.6 GHz 1 GHz 10.2 GHz 11 GHz 0.975 GHz 1.025 GHz
21.2 GHz 2.12 GHz 19.08 GHz 20.67 GHz 21.73 GHz
• MS2667C
MS2667C Signal generator Results
20 kHz 0.999 992 GHz 1.000 008 GHz 19 kHz 21 kHz
200 kHz 0.999 92 GHz 1.000 08 GHz 190 kHz 210 kHz
1 GHz 2 MHz 0.999 2 GHz 1.000 8 GHz 1.9 MHz 2.1 MHz
10 MHz 0.996 GHz 1.004 GHz 9.5 MHz 10.5 MHz
100 MHz 0.96 GHz 1.04 GHz 95 MHz 105 MHz
2 GHz 0.2 GHz 1.8 GHz 1.9 GHz 2.1 GHz
100 kHz 4.21 GHz 4.29 GHz 95 MHz 105 MHz
4.25 GHz 1 GHz 3.85 GHz 4.65 GHz 0.95 GHz 1.05 GHz
8.5 MHz 0.85 GHz 7.65 GHz 8.075 GHz 8.925 GHz
100 MHz 9.96 GHz 10.04 GHz 95 MHz 105 MHz
10 GHz 1 GHz 9.6 GHz 10.4 GHz 0.95 GHz 1.05 GHz
20 GHz 2 GHz 18 GHz 19 GHz 21 GHz
100 MHz 14.96 GHz 15.04 GHz 95 MHz 105 MHz
15 GHz 1 GHz 14.6 GHz 15.4 GHz 0.95 GHz 1.05 GHz
30 GHz 1.5 GHz 28.5 GHz 28.5 GHz 31.5 GHz
Center
frequency
Span
f
1
f
2
Minimum
value
f
2
' – f
1
'
0.8
Maximum
value
Center
frequency
Span
f
1
f
2
Minimum
value
f
2
' – f
1
'
0.8
Maximum
value
