SECTION 6 PERFORMANCE TESTS
6-51
(4) Procedure
Step Procedure
1 Press the spectrum analyzer [Preset] key.
2 Operate All Cal.
3 Set the signal generator MG3633A as shown below.
OUTPUT FREQ....................................100 MHz
OUTPUT LEVEL ..................................... 0 dBm
4 Set the spectrum analyzer as shown below.
Center Freq............................................100 MHz
Span.......................................................... 15 kHz
Reference Level ........................................ 0 dBm
RBW........................................................... 3 kHz
5 Press the [→ CF] key to move the signal spectrum peak to the center.
6 Press [Marker] key in that order to set the marker to ∆ marker.
7 Set RBW and SPAN as shown in the table on the next page and measure the level deviation
(error) of each RBW by following steps 8 and 9 below.
8 Press [Peak Search] key to conduct peak search and move the current marker to the peak point
of the signal spectrum.
9 Read the ∆ marker level value.
To Next Page
