SECTION 6 PERFORMANCE TESTS
6-58
Step Procedure
13 Measure at each setting shown in the table below according to steps 8 to 12.
Leftmost peak The 18th peak numbered from the leftmost peak
Spectrum analyzer Signal Generator AM SWT TIME 90 % of specification
setting SWP TIME modulation frequency calculated min/max
50 ms 400 Hz 38.25 ms/51.75 ms
200 ms 100 Hz 153 ms/207 ms
2 s 10 Hz 1.53 s/2.07 s
20 s 1 Hz 15.3 s/20.7 s
200 s 0.1 Hz 99 s/261 s
