APPENDIX C
C-8
Signal Measurement
Min. Results Max.
generator Resokution
500MHz 1Hz 499.999 989MHz 500.000 011MHz
500MHz 10Hz 499.999 98MHz 500.000 02MHz
500MHz 100Hz 499.999 9MHz 500.000 1MHz
500MHz 1kHz 499.999MHz 500.001MHz
Amplitude display accuracy
ATT
A B Error (dB)=A+B Spec
setting (dB)
0 0 (reference) 0 (reference) 0 (reference)
5 ±0.4dB
10 ±0.4dB
15 ±0.4dB
20 ±0.4dB
25 ±1.0dB
30 ±1.0dB
35 ±1.0dB
40 ±1.0dB
45 ±1.0dB
50 ±1.0dB
55 ±1.0dB
60 ±1.0dB
65 ±1.0dB
70 ±1.0dB
75 ±1.5dB
80 ±1.5dB
85 ±1.5dB
90 ±2.5dB
DATE
SERIAL NO.
Tested by
MS2665C Performance Test Record
(6/12)
Frequency measurement accuracy
•
Log scale Fidelity
ATT ∆ marker
Calibration factor (dB) readout (dB)
