APPENDIX C
C-16
Signal Center
Span
Band Center frequency
generator frequency (Mixing order) Minimum value Maker value Maximum value
10kHz 499.999 5MHz 500.000 5MHz
500MHz 500MHz 200kHz 0 (1) 499.99MHz 500.01MHz
100MHz 495MHz 505MHz
10kHz 4.999 999 4GHz 5.000 000 6GHz
5GHz 5GHz 200kHz 1– (1) 4.999 99GHz 5.000 01GHz
100MHz 4.995GHz 5.05GHz
10kHz 7.499 999 3GHz 7.500 000 7GHz
7.5GHz 7.5GHz 200kHz 1+ (1) 7.499 99GHz 7.500 01GHz
100MHz 7.495GHz 7.505GHz
20kHz 11.999 998 8GHz 12.000 001 2GHz
12GHz 12GHz
200kHz
2+ (2)
11.999 99GHz 12.000 01GHz
100MHz 11.995GHz 12.005GHz
1GHz 11.95GHz 12.05GHz
30kHz 19.999 998 1GHz 20.000 001 9GHz
20GHz 20GHz
200kHz
3+ (3)
19.999 99GHz 20.000 01GHz
100MHz 19.995GHz 20.005GHz
1GHz 19.95GHz 20.05GHz
10kHz 28.999 998 9GHz 29.000 001 1GHz
29GHz 29GHz
200kHz
4+(4)
28.999 99GHz 29.000 01GHz
100MHz 28.996GHz 29.005GHz
1GHz 28.95GHz 29.05GHz
(2/12)
DATESERIAL NO.
Tested by
Reference oscillator stability
•
Frequency stability (aging rate)
•
Temparature stability
Description Min. Result Max.
Frequency stability/day –2×10
–8
+2×10
–8
Description Min. Result Max.
Temparature stability –5×10
–8
+5×10
–8
Frequency readout accuracy
MS2667C Performance Test Record
