SECTION 1 GENERAL
1-8
Optional Accesories (2/2)
Model · Order No. Name Remarks
J0064A Coaxial to 7 GHz band waveguide 5.8 to 8.6 GHz, BRJ-7 · N-J
adaptor
J0064C Coaxial to 10 GHz band waveguide 8.2 to 12.4 GHz , BRJ-10 · N-J
adaptor
J0007 GP-IB Cable 408JE-101
J0008 GP-IB Cable 408JE-102
J0742A RS232C Cable D-sub 25 pins (straight)
J0743A RS232C Cable For IBM PC/AT compatible, D-sub 9 pins (cross)
Peripheral Equipment
External Mixer (Oleson Microwave Labs Products)
Model · Order No. † Name † Remarks †
M42HW Equipmentnal Mixer 18 to 26.5 GHz
M28HW External Mixer 26.5 to 40 GHz
M22HW External Mixer 33 to 50 GHz
M19HW External Mixer 40 to 60 GHz
M15HW External Mixer 50 to 75 GHz
M12HW External Mixer 60 to 90 GHz
M10HW External Mixer 75 to 110 GHz
† Please specify the model/order number, name, and quantity when ordering.
