SECTION 1 GENERAL
1-13
(Continued)
Model MS2667C
Relative:
±1.5dB (9kHz to 3.2GHz, band 0, RF ATT 10dB), ±1.0dB (100kHz to 3.2GHz, band 0, RF ATT 10dB)
±1.5dB (3.1 to 8.1GHz, band 1, RF ATT 10dB), ±3.0dB (8.0 to 15.3GHz, band 2, RF ATT 10dB)
Frequency response ±4.0dB (15.2 to 22.4GHz, band 3, RF ATT 10dB), ±4.0dB (22.3 to 30.0GHz, band 4, RF ATT 10dB)
*After pre-selector tuning at band 1, 2, 3 and 4,referenced to midpoint between highest and lowest frequency
deviation in each band.
Absolute:
±5.0dB (9kHz to 30.0GHz, RF ATT 10dB, referenced to 100MHz)
*At band 1, 2, 3, 4, after pre-selector tuning
Scale: 10div
Log scale: 10, 5, 2, 1dB/div
Linear scale: 10, 5, 2, 1%/div
Fidelity (after calibration)
Scale Fidelity Log scale: ±0.4dB (0 to 20dB), ±1.0dB (0 to 70dB), ±1.5dB (0 to 85dB), ±2.5dB (0 to 90dB)
Linear scale: ±4% of reference level
Marker level resolution
Log scale: 0.01dB
Linear scale: 0.02% of reference level
2nd harmonic distortion:
60dBc (10 to 200MHz, band 0, mixer level: 30dBm)
70dBc (0.2 to 1.55GHz, band 0, mixer level: 30dBm)
90dBc or average noise level (1.55 to 15GHz, band 1, 2, 3, 4, mixer level: 10dBm)
Two signal 3rd order intermodulation distortion:
70dBc (10 to 100MHz), 80dBc (0.1 to 8.1GHz)
Spurious response 75dBc or noise level (8.1 to 26.5GHz)
75dBc or noise level (typical, 26.5 to 30GHz)
*Frequency diffrence of two signals 50kHz, mixer input level: 30dBm
Image response:
65dBc (Input frequency 18GHz), 60dBc (Input frequency 22 GHz)
55dBc (Input frequency 30GHz)
Multiple respose/Out of band response: 60dBc (22GHz), 55dBc (30GHz)
1dB gain compression 5dBm (100MHz, at mixer input level)
Setting range: 20ms to 1000s
Sweep time (manual settable, or automatically settable according to span, resolution bandwidth and video bandwidth)
Accuracy: ±15% (20ms to 100s), ±25% (110s to 1000s), ±1% (digital zero span mode)
Sweep mode Continious, single
Time domain sweep mode Analog zero span, digital zero span
Zone sweep Sweeps only in frequency range indicated by zone marker
Tracking sweep Sweeps while tracking peak points within zone marker (zone sweep also possible)
Numbers of points 501
NORMAL: Simultaneously displays max. and min. points between sample points
POS PEAK: Displays max. point between sample points
Detection mode NEG PEAK: Displays min. point between sample points
SAMPLE: Displays momentary value at sample points
Detection mode switching uncertaity: ±0.5dB (at reference level)
Display Color TFT-LCD, Size 5.5", Number of colors: 17 (RGB, each 64-scale settable),
Intensity adjustment: 5 steps settable
Trace A: Displays frequency spectrum
Trace B: Displays frequency spectrum
Trace Time: Displays time domain waveform at center frequency
Trace A/B: Displays Trace A and Trace B simultaneously, simultaneous sweep of same frequency, alternate
Display function sweep of independent frequencies
Trace A/BG: Display frequency region to be observed (background) and object band (foreground) selected
from background with zone marker simultaneously, alternate sweep
Trace A/Time: Displays frequency spectrum, and time domain waveform at center frequency simultaneously
Trace move/calculation: AB, BA, AB, A+BA, AB+DLA
Storage functions NORMAL, VIEW, MAX HOLD, AVERAGE, CUMULATIVE, OVERWRITE
Functions Sweep Amplitude
