Installation GT3000
28 IMGT30017EN
3A.3.2 Power cables and power fuses
Select power cables and power fuses according to the following tables. Use copper input power cables and motor cables with a 600-690 VAC
rating. Use cable with a 1000 VDC rating for dynamic brake wiring.
Table 3A.3.2 Power Cable and Fuses Sizing ( 380-460 VAC; 510-650 V
DC
)
F=Three-phase supply voltage 380V, 415V, 440V, 460V, 480V / Y=510-650V
DC
±10%
Model Supply Main Fuses
1
Fuses type) Cables section Terminals
Max torque
Max Line Short
Circuit Current
[A] (UL) AWG mm
2
Nm lbf ft kA
SVGT0P3F AC/DC
5x3/2 FWP-15A 14 2,5 10 (AWG max) 0,5 4.425 5
SVGT0P4F AC/DC
10x3/2 FWP-15A 14 2,5 10 (AWG max) 0,5 4.425 5
SVGT0P6F AC/DC
15x2 FWP-20A 14 2,5 10 (AWG max) 0,5 4.425 5
SVGT008F AC
15x3 FWP-20A 14 2,5 10 (AWG max) 0,5 4.425 5
SVGT008F DC
20x2 FWP-25A 14 2,5 10 (AWG max) 0,5 4.425 5
SVGT011F AC
20x3 FWH-40A 12 4 10 (AWG max) 0,5 4.425 5
SVGT011F DC
25x2 FWP-40A 12 4 10 (AWG max) 0,5 0.37 5
SVGT015F AC
30x3 FWH-45A 10 6 10 (AWG max) 0,5 0.37 5
SVGT015F DC
30x2 FWP-45A 10 6 10 (AWG max) 0,5 0.37 5
SVGT018F AC
35x3 FWH-45A 10 6 10 (AWG max) 0,5 0.37 5
SVGT018F DC
40x2 FWP-50A 10 6 10 (AWG max) 0,5 0.37 5
SVGT022F AC
50x3 FWH-60A 8 10 6 (AWG max) 1,2 0.88 5
SVGT022F DC
50x2 FWP-60A 8 10 6 (AWG max) 1,2 0.88 5
SVGT028F AC
50x3 FWH-70A 8 10 6 (AWG max) 1,2 0.88 5
SVGT028F DC
60x2 FWP-90A 8 10 6 (AWG max) 1,2 0.88 5
SVGT030F AC 50x3 FWH-70A 8 10 6 (AWG max) 1,2 0.88 5
SVGT030F DC 60x2 FWP-90A 8 10 6 (AWG max) 1,2 0.88 5
SVGT036F AC 60x3 FWH-100A 6 16 4(AWG max) 2 1.47 5
SVGT036F DC 80x2 FWP-125A 6 16 4(AWG max) 2 1.47 5
SVGT045F AC 70x3 FWH-150A 3 25 35 2,5 1.84 5
SVGT045Y DC 90x2 FWP-125A 3 25 35 2,5 1.84 5
SVGT053F AC 90x3 FWH-200A 2 35 35 2,5 1.84 10
SVGT053Y DC 125x2 FWP-175A 2 25 35 2,5 1.84 10
SVGT066F AC 100x3 FWH-200A 2 35 35 2,5 1.84 10
SVGT066Y DC 150x2 FWP-175A 2 35 35 2,5 1.84 10
Input Output
SVGT086F AC 125x3 FWH-225A 2/0 70 M6 M8 10 7.37 10
SVGT086Y DC 175x2 FWP-225A 2/0 70 M6 M8 10 7.37 10
SVGT108F AC 175x3 FWH-225A 3/0 95,0 M6 M8 10 7.37 10
SVGT108Y DC 200x2 FWP-225A 4/0 95,0 M8 M8 10 7.37 10
SVGT125F AC 200x3 FWH-300A 4/0 95 M8 M8 10 7.37 10
SVGT125Y DC 300x2 FWP-400A 250 95 M8 M8 10 7.37 10
SVGT150F AC 250x3 FWH-300A 250 120 M8 M8 10 7.37 10
SVGT150Y DC 350x2 FWP-400A 2/0x2P 120 M8 M8 10 7.37 10
SVGT166F AC 250x3 FWH-300A 250 120 M8 M8 10 7.37 10
SVGT166Y DC 350x2 FWP-400A 2/0x2P 120 M8 M8 10 7.37 10
1
Standard gG fuses with current rating: 1.3 times GT3000 rated current for AC power supply can be used on CE market.
