GT300 Installation
IMGT30017EN 37
JP1 ON EEprom write protection EEprom
1-2
SVGT200-340F (SVGT520-670F) It changes O.C. threshold
JP2
3 2 1 2-3
SVGT420-470F (SVGT780F-940M) For all other sizes: all pins open. Default
1-2
JP3
3 2 1 2-3
Third phase for O.C. protection (GTA1 028)
1-2 Analog output PWM0JP4
3 2 1
2-3 Analog output VA (default)
1-2 Analog output ±10V or 0÷10V (default)JP5
3 2 1
2-3 Analog output 4-20mA
Analog outputs
1-2 Analog output PWM1JP6
3 2 1
2-3 Analog output VB (default)
1-2 Analog output ±10V or 0÷10V (default)JP7
3 2 1
2-3 Analog output 4-20mA
JP8 OFF Reserved (SW Download)
JP13 OFF Reserved (Alternators)
JP14 ON Reserved
1-2 Connects TX232 to X3 for Keypad Advanced (default)JP1
5
3 2 1
2-3 Connects I2C clock to X3, only for future development
1-2 Connects RX232 to X3 for Keypad AdvancedJP1
6
3 2 1
2-3 Connects I2C data to X3, only for future development
Serial link
1-2 RX - RS232 (default)JP1
7
3 2 1
2-3 RX - RS485
JP18 ON
RS485 line termination (221) enabled
JP19 ON
In OFF exclude the Vcmin HW protection (TL).
It is not installed (OFF) on the drive with suffix 10.
JP22 ON Select the source of CK for serial link on X7, :ON = CK output for SIOVA board
JP23 OFF It connects 0V of control to them of I/O ( Encoder+ 24Vdc inputs)
ON At XM1-5 terminal, the supply (+5V) is available for encoder (default)
SW1 - 1
OFF External power supply 12-24V
ON
Load resistor (121) connected to channel A
SW1 - 2
OFF
ON
Load resistor (121) connected to channel B
SW1 3
OFF
Encoder
ON
Load resistor (121) connected to channel Z
SW1 - 4
OFF
ON
Current input on XM1-28/29 (R=475)
SW3 - 1
OFF Voltage input on XM1-28/29 (default)
ON
Current input on XM1-26/27 (R=475)
SW3 - 2
OFF Voltage input on XM1-26/27 (default)
Analog inputs
ON Pull-up to 10V on XM1-26/27
SW3 3
OFF (default)
ON Pull-down to 0V on XM1-26/27
SW3 - 4
OFF (default)
GASPA board
ON RS485 available
DIP1 1
OFF
ON RS485 available
DIP1- 2
OFF
ON tristate signal for RS485, normally not used
DIP1– 3
OFF
Encoder
ON 7,5V available on the pins1-6 (don’t use)
DIP1- 4
OFF
