29 | ANYLOAD OCS Series Electronic Crane Scale User’s Guide
SCALE ADDRESS
o
For multiple scale’s application, address can be assigned to identify the
uniqueness. Scale
sends out address number in the serial
communication protocol.
o S
CALE
A
DDRESS
can be assigned from 00 to 99
o By default, S
CALE
A
DDRESS
is set to 00
OUTPUT MODE
o
There are three option modes of data output: “0” continuous mode,
“1” manual mode,
and “2” request mode.
o In “0” continuous mode, the scale sends out data continuously all
the time. In “1” manual mode, scale only sends data out when key
is pressed while “2” request mode, the scale waits for incoming
request from serial communication port and answer the request
with specified data.
o The default O
UTPUT
M
ODE
is set to “0” continuous way.
To learn more about serial communication protocol, refer to Technical Manual
