6 | ANYLOAD OCS Series Electronic Crane Scale User’s Guide
o Scale’s maximum capacity will display on the screen. For example, the
scale will show 5000kg if its full capacity was set to 5000kg
o
Battery Check will also be performed. If battery is working fine, the
screen flashes battery charge
twice.
Refer to Battery section of this guide for more information about battery
recharging.
o Finally, the screen will show detection message while scale is detecting
its load and A
UTO
‐Z
ERO will function
to Z
ERO
status when the
A
UTO
‐Z
ERO
function is enabled.
To learn more about Auto‐Zero function refer to Auto‐Zero Range in Scale’s
Configuration function.
After the scale is completely powered up and initialized, it is ready for weighing
operations.
NOTE:
Scale must be working at the battery voltage ranging from 6.8V to 5.8V.
Recharge the battery if needed.
