[PWR] power switch: The power switch is not of the traditional “click”
operation but microprocessor controlled, this is to facilitate the sleep timer.
To switch the receiver On, press and hold the [PWR] key for more than
1.5 seconds. Similarly to switch the receiver Off, press and hold the [PWR]
key for more than 1.5 seconds.
Full microprocessor reset: Later in this manual reference is made to FULL
microprocessor reset. The AR2700 takes about 30 seconds to recover
following a FULL reset as all memory and search data has to be deleted...
be patient as 30 seconds feels like a very long time when you are waiting.
Remember also, when there is no memory or search data, the AR2700 will not
scan or search until you have input new data.
1-1 Accessories supplied
4 x AA internal high capacity rechargeable NiCad batteries
Mains charger
DC power lead with cigar lighter plug
Telescopic whip aerial
Belt clip with two screws
Hand strap
Operating manual
(2) Table of contents
1 Introduction and accessories ............................. 1
1-1 Accessories supplied ............................................ 2
2 Table of contents ................................................ 2
3 Major features ..................................................... 4
4 Precautions ......................................................... 6
4-1 Location ............................................................... 6
4-2 Looking after your receiver .................................... 6
4-3 Power requirements .............................................. 6
4-4 NiCads and charging ............................................ 7
4-5 Aerial (antenna) connection .................................. 8
5 Controls and functions ....................................... 9
TOP PANEL ......................................................... 9
5-1 Aerial (antenna) input ........................................... 10
5-2 Earphone connection / speaker connection ........... 10
5-3 [DIAL] - tuning control / selector ............................ 10
5-4 Squelch control ..................................................... 10
5-5 Volume control ...................................................... 11
FRONT PANEL .................................................... 11
5-6 Liquid Crystal Display LCD ................................... 11
5-7 Keypad (extensive information) ............................. 11
5-8 Internal loudspeaker ............................................. 22
LEFT HAND SIDE ................................................ 22
5-9 [2ndF] function key ............................................... 22
5-10 [MONI] monitor key .............................................. 23
5-11 [K.LOCK] keypad lock key .................................... 23
