AR2700 operating manual
63
(18) Specification
Frequency coverage: 500 kHz - 1300 MHz no gaps
(input accepted from 100 kHz)
Receive modes: NFM, WFM, AM
Sensitivity: 10 - 400 MHz NFM = 12dB SINAD
NFM 0.5 uV AM = 10dB S/N
AM 0.8 uV WFM = 30dB S/N
WFM 6.0 uV
400 - 1000 MHz
NFM 0.7 uV
WFM 6.0 uV
1000 1500 MHz
NFM 1.5 uV
Selectable tuning steps: AM & NFM
5kHz, 6.25kHz, 9kHz, 10kHz,
12.5kHz, 20kHz, 25kHz, 30kHz,
50kHz & 100kHz
WFM 50kHz & 100kHz
Memory capacity: 500 ch total, 10 banks x 50 ch
Search banks: 10
Pass channels: 50 ch
VFO: One
Priority channel: One
Scan & search rate: 30ch/sec approx
Aerial input: 50 OHM BNC
Audio output: 110mW (6V 10%THD 8 OHM)
Power requirements: 4.8V from 4 x AA internal NiCads
6.0V manganese / alkaline
9.0 - 16V external
Current consumption: 95mA squelched - stand by
140mW (receive 50mW audio)
E&OE Rev 1.1 © 1995 AOR, LTD.
