54
Quality for Professionals
专业质量
5.5 Wheel sensor (item no.: 00410-2-007)
5.5
车轮传感器（项目编号：
00410-2-007
）
The radar sensor measures the driving speed [km/h]. This is
displayed on the control module and the seed volume is
automatically regulated by the sowing shaft speed control. This
means that the required volume of seed per hectare is always
maintained, even if the driven speed deviates slightly from the
speed specified in the calibration test.
通过雷达传感器测量行车速度【千米/时】。这在控制模块上显示，且
播种轴转速控制器会自动调节播种量。这意味着，即使驱动速度与校
准试验规定的速度略有不同，仍可以始终维持每公顷需要的种子量。
The sensor can detect both the magnets provided and all
metals (screw heads, wheels bolts, etc.)
传感器可以对规定磁体和所有金属材料（螺钉头、车轮螺栓等）进行
检测
Fig.: 12
图：12
Connection:
连接：
12-pin connector on the control module
控制模块上的 12 插孔连接器
Settings:
设置：
See under item 6.5
参见第 6.5 项
Cable length:
电缆长度：
5m
5 米
Where installed:
安装位置：
The magnet is installed on the inside of the wheel rim. The sensor must be
fastened at a distance of min. 5 mm to max. 10mm from the magnets (or
wheel bolts, nuts, etc.) If the sensor is actuated, the LED on the rear side
illuminates.
磁体安装在轮辋内侧。传感器必须固定在距离磁体（或车轮螺栓、螺母等）5 ~ 10
毫米
的位置
。
如果激活传感器，后侧的 LED 灯点亮。
Scope of delivery:
1 sensor and 2 fastening nuts, 8 neodymium magnets (very strong), cable ties,
1 fastening plate
