57
Quality for Professionals
专业质量
Where installed:
安装位置：
Because most tillage implements are raised and lowered when being used, it is best
to install the sensor at, or on, the tractor's lever arm (see figure above). The sensor
can also be installed elsewhere where there is a mechanical movement of more
than 50 mm. There should be a distance of at least approx. 5 mm between the
sensor and the magnet. For coupled tillage implements, the sensor can be installed
on the chassis, because the hoist is not being used here. The programming (for the
position in which work is to be carried out) can be adjusted for this.
由于大多数耕作农具在使用时需要上下来回操作，因此最好在拖拉机杠杆臂及其上部
安装传感器（见上图）。传感器还可以安装在机械运动超过 50 毫米的其他部位。传感
器与磁体之间的间距应至少保持约 5 毫米。对于耦合的耕作农具，因为此处并未使用
卷扬机，所以可将传感器安装在底盘上。对此，可调整程序设计（即将开始作业的位
置）。
This is explained in item 6.8.
第 6.8 项中对此进行了解释。
Scope of
delivery
：
输送范围：
1 sensor, 2 magnets incl. screws/bolts, cable binders, 1 fastening plate, 2 PVC nuts
for the sensor;
1 个传感器和 2 个磁体，包括供传感器使用的螺丝/螺栓、电缆夹子、1 个固定板、2
个 PVC 螺母；
Note: The sensor must not be screwed on too tightly (tensioned)!
注意：传感器不得栓接太紧（拉紧）！
