61
Quality for Professionals
专业质量
tractor. If the machine is now lifted out, the path between the two points
becomes longer and the pull switch switches the sowing shaft off. However, the
switch can also be mounted parallel to the cylinders, in parallelograms, etc.,
whereby a relative movement takes place between two points during the lifting
process. Whether sowing is to be carried out with actuated or non-actuated
switch, can be defined in the programming.
使用 1 个弹簧（用于长度补偿）和 1 个链条，可能将设备提升过程中相对移动的
2 个点连接。开关由长度变化控制，因此关闭播种轴。与拖拉机联动装置传感器
上拉杆类似，拉线开关可以安装在三点上并通过链条拉紧，如拖拉机的联结装置。
如果目前机器处于提升状态，两点之间的距离变长，拉线开关关闭播种轴。虽然
此开关也可以平行于汽缸的方式安装（呈平行四边形），但在提升过程中，两点之
间会发生相对运动。无论是否以驱动或非驱动开关进行播种作业，播种均能在程
序设计中进行规定。
This is explained in point 6.8.
第 6.8 点中对此进行了解释。
Scope of delivery:
输送范围：
1 sensor
1 个传感器
1 fastening plate incl. screws/bolts
1 个固定板，包括螺钉/螺栓
