BATTERY
MODULE
The LINX Battery module can be used to monitor and display
the charge state of up to three (3) independent batteries
simultaneously.
Each battery can be given a unique name (up to 16 characters) and then be
congured to operate with your Switchboard accessory via the Switchboard
module. (Refer to the section on the Switchboard module for further details).
1. Press and hold Battery 1 to show its settings page.
Note: The greyed-out checkbox indicates that Battery 1 is the battery the LINX
Controller is connected to for power. Hence it is active by default and cannot be
de-activated.
CONFIGURING BATTERY MODULE
2. Activate each battery by tapping the
checkbox in the top right corner.
To Next Page
