ARB LINX LX100 User Manual

| LX100 VEHICLE ACCESSORY INTERFACE KIT OPERATION GUIDE
PAGE 7
01.
WHAT’S IN
THE BOX?
Congratulations on the purchase of your brand new LINX. Inside the
box, you’ll nd each of the components required to get the system
up and running for your next 4x4 adventure.
NOTES
• The LINX Display
02
was specically designed to withstand the extremes of heat and cold. It has a metal coupling on the
back to connect it to the magnets on the LINX Display Gimbal Mount .
• The LINX Controller
01
and wiring looms
05
are normally mounted under the dash, however this may vary depending on
the vehicle.
• The DIN rail
06
comes assembled to the back of the LINX controller
01
and is used for securing the unit.
• The USB connection can be used to power and charge the LINX Display, and provide the communications channel between the
LINX Controller and LINX Display.
LINX CONTROLLER
LINX DISPLAY
LINX DISPLAY
GIMBAL MOUNT
USB CABLE
WIRING LOOMS (x3)
DIN RAIL 180MM
01
02
03
04
06
05
03
