PAGE 38
PRESSURE CONTROL MODE LIST
With pressure control installed the Current Pressure and Target Pressure elds
are activated along with the Pressure Control Mode list. Tap on the dropdown list
to select from the 3 different modes.
PRESSURE CONTROL MODES
Pressure Off means no air ow from the compressor, but residual pressure may
still be in the air line.
Pressure Control will turn on the compressor and the Pressure Control Valve will
try to inate/deate to achieve the Target Pressure to a value less than or equal to
the Maximum System Pressure setting.
Pressure Max will turn on the compressor, and open the Pressure Control Valve,
thereby opening up a straight connection between the compressor and air line
which is useful when using a blow gun on the air line.
Cancel is used to back out of the menu (ie same as tapping the Back button).
1. Tap the 'dropdown list' to view the list of modes.
2. Tap the desired Pressure Control Mode to
select it.
