BIOS CONFIGURATION
40
For greater 2TB expansion:
• If your system installed on the volume, does not expand the
volume capacity greater 2TB, currently OS can not support boot
up from a greater 2TB capacity device.
• Expand over 2TB used 64-bit LBA mode. Please make sure
your OS supports 64-bit LBA before expand it.
• Volume Set Migration
Migrating occurs when a volume set is migrating from one RAID
level to another, when a volume set strip size changes, or when
a disk is added to a RAID set. Migration state is displayed in the
volume state area of the “Volume Set Information” screen.
3.6.3.4 Display Volume Set Info.
To display volume set information, move the cursor bar to the
desired volume set number and then press the Enter key. The
“Volume Set Information” will be shown. You can only view the
information of this volume set in this screen, not modify it.
I/O Port Addr:FD700000h, F2 (Tab): Select Controller, F10: Reset System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
View System Events
Clear Event Buffer
Hardware Monitor
System information
Physical Drive Information
Physical Drive Information
Create Pass-Through Disk
Modify Pass-Through Disk
Delete Pass-Through Disk
Identify Selected Drive
View Drive Information
3.6.4 Physical Drives
Move the cursor bar to the “Physical Drives" function” on the main
menu and then press the Enter key to perform the operations
listed above.
