WEB BROWSER-BASED CONFIGURATION
6.7.3 Delete Pass-Through Disk
To delete a pass-through drive from the pass-through drive pool,
move the mouse cursor bar to the main menus and click the “De-
lete Pass Through” link.
After you complete the selection, mark the checkbox for “Conrm
The Operation” and click the “Submit” button to complete the
delete action.
6.7.4 Identify Selected Drive
To prevent removal of the wrong drive, the selected fault LED will
blink so as to physically locate the intended disk when “Identify
Selected Drive” is selected.
To identify the selected drive from the drives pool, click “Identify
Selected Drive”. The “Select The IDE Device For Identication”
screen appears mark the check box for the SATA device from the
drive pool. After completing the selection, click on the “Submit”
button to identify selected drive.
6.8 System Controls
6.8.1 System Cong
To set the RAID controller system function, move the cursor to
the main menu and click the “Raid System Function” link. The
“Raid System Function” menu will show all items, then select the
desired function.
