3.10.4 Settings
The settings necessary for the implementation of InterMiCOM are contained within two
columns of the relay menu structure. The first column entitled “INTERMICOM COMMS”
contains all the information to configure the communication channel and also contains the
channel statistics and diagnostic facilities. The second column entitled “INTERMICOM
CONF” selects the format of each signal and its fallback operation mode. The following table
shows the relay menu for the communication channel including the available setting ranges
and factory defaults.
Setting Range
Menu Text Default Setting
Min Max
Step Size
INTERMICOM COMMS
IM Output Status 00000000
IM Input Status 00000000
Source Address 1 1 10 1
Receive Address 2 1 10 1
Baud Rate 9600 600 / 1200 / 2400 / 4800 / 9600 / 19200
Remote Device Px40 Px30 / Px40
Ch Statistics Invisible Invisible / Visible
Reset Statistics No No / Yes
Ch Diagnostics Invisible Invisible / Visible
Loopback Mode Disabled Disabled / Internal / External
Test pattern 11111111 00000000 11111111 -
3.11 Ethernet Rear Port (option)
If UCA2.0 is chosen when the relay is ordered, the relay is fitted with an Ethernet interface
card.
See P44x/EN UC/E44 section 4.4 for more detail of the Ethernet hardware.
