Update Documentation P44x/EN AD/E44
MiCOM P441, P442 & P444 Page 63/82
Send to Relay
Send the open GOOSE configuration file to the connected relay.
Receive from Relay
Extract the current GOOSE configuration from the connected relay.
Communications Setup
Displays the Local Communication Settings dialogue box, enabling you to select or configure
the communication settings.
The toolbar
Open
Opens an existing GOOSE configuration file.
Save
Save the active document.
Print
Display the Print Options dialog, enabling you to print the current configuration.
View Properties
Show associated properties for the selected item.
How to Use the GOOSE Editor
The main functions available within the GOOSE Editor module are:
• Retrieve GOOSE configuration settings from an IED
• Configure GOOSE settings
• Send GOOSE configuration settings to an IED
• Save IED GOOSE setting files
• Print IED GOOSE setting files
Retrieve GOOSE configuration settings from an IED
Open a connection to the required device by selecting Open Connection from the Device menu. Refer
to Section 2.1.1.6 & 2.1.1.7 for details on configuring the IED communication settings.
Enter the device address in the Establish Connection dialogue box.
Enter the relay password.
Extract the current GOOSE configuration settings from the device by selecting Receive from Relay
from the Device menu.
