P44x/EN AD/E44 Update Documentation
Page 38/82
MiCOM P441, P442 & P444
Menu text Default setting Setting range Step size
Min Max
GROUP 1
AUTORECLOSE
AUTORECLOSE MODE
AUTORECLOSE LOCKOUT
Block A/R
1111 1111
1111 1111
111
Bit 0: Block at tZ2
Bit 1: Block at tZ3,
Bit 2: Block at tZp
Bit 3: Block for LoL Trip,
Bit 4: Block for I2> Trip,
Bit 5: Block for I>1 Trip,
Bit 6: Block for I>2 Trip,
Bit 7: Block for V<1 Trip,
Bit 8: Block for V<2 Trip,
Bit 9: Block for V>1 Trip,
Bit 0A: Block for V>2 Trip,
Bit 0B: Block for IN>1 Trip,
Bit 0C: Block for IN>2 Trip,
Bit 0D: Block for Aided DEF Trip.
Bit 0E: Block ZSP Trip
Bit 0F: Block IN>3 Trip
Bit 10: Block IN>4 Trip
Bit11: Block PAP Trip
Bit12: Block Therm Overload Trip
4.9 Event recorder
Report Type These cells are numbers representative of the occurrence. They form
a specific error code which should be quoted in any related
correspondence to AREVA T&D P&C Ltd.
Report Data
