P44x/EN AD/E44 Update Documentation
Page 28/82 MiCOM P441, P442 & P444
2. APPLICATION OF INDIVIDUAL PROTECTION FUNCTIONS
2.1 Configuration column
The following table shows the Configuration column:-
Menu text Default setting Available settings
CONFIGURATION
Restore Defaults No Operation No Operation
All Settings
Setting Group 1
Setting Group 2
Setting Group 3
Setting Group 4
Setting Group Select via Menu Select via Menu
Select via Optos
Active Settings Group 1 Group1
Group 2
Group 3
Group 4
Save Changes No Operation No Operation
Save
Abort
Copy From Group 1 Group1,2,3 or 4
Copy To No Operation No Operation
Group1,2,3 or 4
Setting Group 1 Enabled Enabled or Disabled
Setting Group 2 Disabled Enabled or Disabled
Setting Group 3 Disabled Enabled or Disabled
Setting Group 4 Disabled Enabled or Disabled
Distance Enabled Enabled or Disabled
Power Swing Enabled Enabled or Disabled
Back-up I> Disabled Enabled or Disabled
Neg Sequence O/C Disabled Enabled or Disabled
Broken Conductor Disabled Enabled or Disabled
Earth Fault O/C Disabled Enabled or Disabled
Zero Sequence Power (*)
(ZSP)
Disabled Enabled or Disabled
Aided DEF Enabled Enabled or Disabled
Volt Protection Disabled Enabled or Disabled
CB Fail & I< Enabled Enabled or Disabled
Supervision Enabled Enabled or Disabled
System Checks Disabled Enabled or Disabled
Thermal Overload (***) Disabled Enabled or Disabled
Internal A/R Disabled Enabled or Disabled
Input Labels Visible Invisible or Visible
Output Labels Visible Invisible or Visible
CT & VT Ratios Visible Invisible or Visible
Record Control Invisible Invisible or Visible
Disturb Recorder Invisible Invisible or Visible
