Structure tools
The structure toolbar enables you to change the stacking order of components.
Bring to Front
Bring the selected components in front of all other components.
Send to Back
Bring the selected components behind all other components.
Bring Forward
Bring the selected component forward one layer.
Send Backward
Send the selected component backwards one layer.
9.9.3 MiCOM Px40 GOOSE editor
To access to Px40 GOOSE Editor menu click on
The implementation of UCA2.0 Generic Object Orientated Substation Events (GOOSE) sets
the way for cheaper and faster inter-relay communications. UCA2.0 GOOSE is based upon
the principle of reporting the state of a selection of binary (i.e. ON or OFF) signals to other
devices. In the case of Px40 relays, these binary signals are derived from the Programmable
Scheme Logic Digital Data Bus signals. UCA2.0 GOOSE messages are event-driven. When
a monitored point changes state, e.g. from logic 0 to logic 1, a new message is sent.
GOOSE Editor enables you to connect to any UCA 2.0 MiCOM Px40 device via the Courier
front port, retrieve and edit its GOOSE settings and send the modified file back to a MiCOM
Px40 device.
