Technical Data P44x/EN TD/E33
MiCOM P441/P442 & P444
Page 7/30
1.6 Output Relay Contacts
Make & Carry 30A for 3s
Carry 250A for 30ms
10A continuous
Break DC: 50W resistive
DC: 37.5W inductive (L/R = 40ms)
AC: 1250VA
AC: 1250VA inductive (P.F. = 0.7)
Maxima: 10A and 300V
Loaded contact: 10,000 operations minimum
Unloaded contact: 100,000 operations minimum
Watchdog Contact
Break DC: 30W resistive
DC: 15W inductive (L/R = 40ms)
AC: 275W inductive (P.F. = 0.7)
The maximum number of output relays that should be configured to be permanently
energized is 50% of those available (minimum 4).
1.7 Field Voltage
The field voltage provided by the relay is nominally 48V dc with a current limit of 112mA. The
operating range shall be 40V to 60V with an alarm raised at <35V.
1.8 Loop through connections
Terminals D17-D18 and F17-F18 are internally connected together for convenience when
wiring, Maxima 5A and 300V.
1.9 Wiring requirements
The requirements for the wiring of the relay and cable specifications are detailed in the
installation section of the Operation Guide (Chapter P44x/EN IN).
